In this guide, we'll clean up the buttons of the Visteon HU and clean the LCD pins in order to fix a low-contrast problem of the display.
We'll need:
In long story short, i recommend window cleaners fluid.
Let's dismount the HU.
Cut of the wired hanger in to U shapes.
Having the HU out, you'll finde 4 Torx screws on the back face. 2 on each side.
![P1080899.jpg P1080899.jpg](https://cdn.fiatforum.com/data/attachments/111/111498-fc9d724dacac1df3497f84ba7a232b81.jpg)
After undoing the screws, the front face will be released BUT beware on the data cable still connected with the main HU.
Gently pull back to unlock.
![P1080900.jpg P1080900.jpg](https://cdn.fiatforum.com/data/attachments/111/111506-6b8a908a049f582cbdd420df44968238.jpg)
![P1080901c.jpg P1080901c.jpg](https://cdn.fiatforum.com/data/attachments/111/111551-c48d17986229c5af4a695a3b13e77342.jpg)
Attention: Each color is different type of screw! Don't mix them up!
Once all are undone, you get the circuit board off.
![P1080904.jpg P1080904.jpg](https://cdn.fiatforum.com/data/attachments/111/111518-6593f9c724c095057d3ca9dafe23f8d9.jpg)
Back to the face plate you'll see this:
![P1080905.jpg P1080905.jpg](https://cdn.fiatforum.com/data/attachments/111/111530-55ccf2048311ae83a3c57f321ca0f60c.jpg)
I suggest not to touch the little graphite buttons marked with the green arrow above. These are the "switches" that the buttons use and need to be clean and moisture free. If you wish, clean them with pure alcohol. (No! Not whiskey!)
.
Removing the black frame that holds the rubber surface, we are finaly on our buttons.
![P1080907.jpg P1080907.jpg](https://cdn.fiatforum.com/data/attachments/111/111535-8462b345221e76e8b4f594075a2e326a.jpg)
Easy to come off, take them and put them on a glass filled with the window cleanter.
Leave them swim in there in order to make the glue-ish surface start rinkle and get unstable.
For the Vulume button, take some strips of cleaning tissue soaked in window cleaner and wrap it around.
![P1080908.jpg P1080908.jpg](https://cdn.fiatforum.com/data/attachments/111/111538-6d4e9d79bb6e1f3de57819b3aab2da1b.jpg)
If you want to refresh the LCD's connector, using the pliers, you bent some metal locks of the circuit board as shown below, and gently pull off the LCD.
![P1080901_b.jpg P1080901_b.jpg](https://cdn.fiatforum.com/data/attachments/111/111514-0b440a1aa015107841d02f4ae53eea05.jpg)
Now, with the 800 sand paper or with the electrical contact cleaner (Recommended) we gently clean the pins as shown on the above pic.
After having our buttons soaked, we take each one of them and start rubbing them with cleaning tissues and more window cleaner.
Needs patience and persistence.
If you are growing nails for any reason (i'm note here to judge
) it's time to use them.
BUT try not TOO much cause you might rip off the black paint (see my 4 button)
Results:
![P1080910.jpg P1080910.jpg](https://cdn.fiatforum.com/data/attachments/111/111541-e1c82e236a82e8265443f447fafec8f9.jpg)
![P1080916.jpg P1080916.jpg](https://cdn.fiatforum.com/data/attachments/111/111547-66ebd12d8c1757b352b48a1fe3c789e7.jpg)
Be patience, be persistent and you'll be rewarder!
Good luck!
PS: Forgive any English language mess up. Even we, Greek Gods, make mistakes!
:worship:
